Waterproof NBR Rubber Cable Gland Anti Bending For Union Pipe

Waterproof NBR Rubber Cable Gland Anti Bending For Union Pipe

  • Waterproof NBR Rubber Cable Gland Anti Bending For Union Pipe
Waterproof NBR Rubber Cable Gland Anti Bending For Union Pipe
Product Details:
Place of Origin: Zhejiang,China
Brand Name: Hnx nylon cable gland
Certification: RoHS, CE, IP68
Model Number: M/PG Type
Payment & Shipping Terms:
Minimum Order Quantity: 10 Pieces
Price: Please contact us.
Packaging Details: 38*25*17mm
Delivery Time: 3-30 Day
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000 Pieces/Day
Contact Now
Detailed Product Description
Material: PA66,UL94-V2 Characteristic: Flexible Pipe Nylon Union
Min Temperature: Dynamic Environment -20 ℃ Performance: Dustproof-electronic
Hermetic Seal: NBR,silicone Rubber Special Part: Anti Bending Spring
High Light:

Waterproof NBR Rubber Cable Gland

,

Union Pipe NBR Rubber Cable Gland

,

Anti Bending NBR Rubber Cable Gland

Silicone Rubber Flexible Nylon Cable Gland For Hose Fitting / Waterproof Union Pipe Rubber Seal​



Product detail

  • External material: PA66(Nylon)
  • Protection degree: IP68
  • Working temperature: - 40 ℃ to 100 ℃, short time to 120 ℃
  • Color:Grey,black,other color can be customized.



Item



Item Conduit Size AG
Thread O.D.
(mm)
GL
Thread Length
(mm)
Code
M Thread
M12 x 1.5 AD10.0 12 8.5 HX-NLKM12 -10.0
M12 x 1.5 AD13.0 12 10 HX-NLKM12 -13.0
M16 x 1.5 16 10 HX-NLKM16 -13.0
M18 x 1.5 18 10 HX-NLKM18 -13.0
M16 x 1.5 AD15.8 16 10 HX-NLKM16 -15.8
M18 x 1.5 18 12.5 HX-NLKM18 -15.8
M20 x 1.5 20 12.5 HX-NLKM20 -15.8
M20 x 1.5 AD18.5 20 12.5 HX-NLKM20 -18.5
M22 x 1.5 22 12.5 HX-NLKM22 -18.5
M20 x 1.5 AD21.2 20 13 HX-NLKM20 -21.2
M24 x 1.5 24 13 HX-NLKM24 -21.2
M25 x 1.5 25 13 HX-NLKM25 -21.2
M25 x 1.5 AD25.0 25 13 HX-NLKM25 -25.0
M25 x 1.5 AD28.5 25 13 HX-NLKM25 -28.5
M27 x 1.5 27 13 HX-NLKM27 -28.5
M30 x 1.5 30 13 HX-NLKM30 -28.5
M32 x 1.5 32 13 HX-NLKM32 -28.5
M32 x 1.5 AD34.5 32 14 HX-NLKM32 -34.5
M36 x 1.5 36 14 HX-NLKM36 -34.5
M40 x 1.5 40 14 HX-NLKM40 -34.5
M40 x 1.5 AD42.5 40 15 HX-NLKM40 -42.5
M48 x 1.5 48 15 HX-NLKM48 -42.5
M50 x 1.5 AD54.5 50 16 HX-NLKM50 -54.5
M63 x 1.5 60 16 HX-NLKM63 -54.5
Item Conduit Size AG
Thread O.D.
(mm)
GL
Thread Length
(mm)
Code
PG Thread
PG7 AD10.0 12.4 8.5 HX-NLKPG7 -10.0
PG9 AD13.0 15.2 10 HX-NLKPG9 -13.0
PG11 AD15.8 18.4 12.5 HX-NLKPG11 -15.8
PG13.5 AD18.5 20.4 12.5 HX-NLKPG13.5 -18.5
PG16 AD21.2 22.5 13 HX-NLKPG16 -21.2
PG21 AD28.5 28.3 13 HX-NLKPG21 -28.5
PG29 AD34.5 37 14 HX-NLKPG29 -34.5
PG36 AD42.5 47 15 HX-NLKPG36 -42.5
PG42 AD54.5 54 16 HX-NLKPG42 -54.5
PG48 59.3 16 HX-NLKPG48 -54.5
Item Conduit Size AG
Thread O.D.
(mm)
GL
Thread Length
(mm)
Code
G Thread
G(PF) 1/4 AD10.0 13.1 8.5 HX-NLKG1/4 -10.0
G(PF) 3/8 AD15.8 16.6 12.5 HX-NLKG3/8-15.8
G(PF) 1/2 20.9 12.5 HX-NLKG1/2-15.8
G(PF) 1/2 AD18.5 20.9 12.5 HX-NLKG1/2-18.5
G(PF) 1/2 AD21.2 20.9 13 HX-NLKG1/2-21.2
G(PF) 3/4 26.4 13 HX-NLKG3/4-21.2
G(PF) 3/4 AD28.5 26.4 13 HX-NLKG3/4-28.5
G(PF) 1 AD34.5 33.2 14 HX-NLKG1-34.5
G(PF) 1 1/4 AD42.5 41.9 15 HX-NLKG1 1/4-42.5
G(PF)1/2 48 15 HX-NLKG1 1/2-42.5
G(PF) 1 1/2 AD54.5 48 16 HX-NLKG1 1/2-54.5
G(PF) 2 60 16 HX-NLKG2-54.5



Usage:

nylon cable waterproof connector is a supporting article for cables, which is mainly used in distribution boxes and distribution cabinets.

The connector can lock the cable, and the other end can be connected to the upper part of the equipment box body, or can be threaded according to the selection.connect to electric equipment with internal threads at the inlet and outlet. General machinery control box, distribution board, machinery.when used for fixing wires and cables, it can effectively clamp cables and achieve the purpose of waterproof. according to the installation materials produced, they can be divided into heat shrink type ( the most commonly used type ), dry wrap type, epoxy resin pouring type and cold shrink type.according to the core material, it can be divided into copper core power cable connector and aluminum core power cable connector.



Company advantages:

Yueqing hongxiang connector manufacturing co., ltd.is a professional manufacturer of various specifications of wire and cable connectors. The main product is a metal cable waterproof connector with a protection grade of ip68.It has the characteristics of large clamping cable range, strong tensile force, waterproof, dustproof,salt resistance, acid and alkali resistance, alcohol resistance, grease and common solvents, etc.Other products include anti-electromagnetic cable connector, porous cable waterproof connector, marine stuffing box, reducer head, brass plug ca
