Hose Clamp Type Flexible Conduit Connector / Zinc Die Casting Emt Connectors

Hose Clamp Type Flexible Conduit Connector / Zinc Die Casting Emt Connectors

  • Hose Clamp Type Flexible Conduit Connector / Zinc Die Casting Emt Connectors
  • Hose Clamp Type Flexible Conduit Connector / Zinc Die Casting Emt Connectors
  • Hose Clamp Type Flexible Conduit Connector / Zinc Die Casting Emt Connectors
Hose Clamp Type Flexible Conduit Connector / Zinc Die Casting Emt Connectors
Product Details:
Place of Origin: Zhejiang,China
Brand Name: Hnx Flexible Conduit Connector
Certification: RoHS, ISO, CE, IP68
Model Number: DKJ
Payment & Shipping Terms:
Minimum Order Quantity: 20-100 Pieces
Price: Negotiation
Packaging Details: 38*25*17mm
Delivery Time: 3-30 Day
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000 Pieces/Day
Contact Now
Detailed Product Description
Material: Zinc Alloy Protection Degree: IP68
Surface Treatment: Galvanized, Ground, Or Chrome Plated Characteristic: Hose Clamp - Type
NO.: EMT Sample: For Free
High Light:

watertight conduit connector

,

flexible straight connector

Hose Clamp Type Flexible Conduit Connector / Zinc Die Casting Emt Connectors



Material: stainless steel and zinc alloy

Coating: zinc, chromium

Protection grade: IP54

Color: metal color

Composition: nut, lining ring, metal ring, screw body, bolt

Purpose: used for connection of metal wire protection tube and thin steel pipe.

Specification: suitable internal diameter 12mm~100mm hose

Packing: Cartons, according to quantitative

Characteristics: it can connect the non threaded steel pipe with the hose, save the silk spinning process, only screw the screw into the pipe, the structure is tight, the strength is high, the water proof, dust proof, salt proof, acid alkali, alcohol, oil and general solvent



Using the method:

(1) take the screw cap and the lining ring on the end of the hose;

(2) screw the metal ring opening along the thread of the hose into the hose;

(3) connect the screw with the nut;

(4) take the bolt down to the outside of the steel tube and tighten the bolt to fix it.



Zinc Die cast -Flex to EMT

CODE SIZE
DKJ-12 3/8"
DKJ-15 1/2"
DKJ-20 3/4"
DKJ-25 1"
DKJ-32 1-1/4"
DKJ-38 1-1/2"
DKJ-50 2"
DKJ-64 2-1/2"
DKJ-75 3"
DKJ-100 4"



Product description
Product material: a.c.f parts are made of high quality thickened zinc alloy, b.e part is made of nitrile rubber, and D is made of iron.
Thread specifications: metric, British, German
Product color: metal color (silver white)
Working temperature: -40 C ~ + 100 C, short time up to +120 C
Protection grade: IP65



Product features:

( 1 ) beautiful appearance, compact structure and high strength
( 2 ) the design and assembly of the sheath and the hose are convenient, and the tensile force is strong
( 3 ) waterproof, dustproof, salt - resistant, acid-base resistant, alcohol, oil, grease and common solvents
( 4 ) in addition to the standard specification, the size and thread standard can be changed as required



Product Introduction

Waterproof metal cable gland type:

Large type cable gland, large range type cable gland, small range type cable gland, length type cable gland, strengthened type cable gland, direct type cable gland, multiple-entry type cable gland, high temperature resistance type cable gland, double locking type cable gland, spiral type cable gland, 90º flexible pipe connector, EMC cable gland, and explosion proof cable gland, etc.

Nylon cable gland type:

Conventional type cable gland, split type cable gland, anti bending cable gland, corrugated tubing cable gland, nylon union for flexible pipe, hose cable gland, etc.

Marine cable gland:

DCG single compression type cable gland, JIS standard type cable gland, TJ clamping type cable gland and TH welded type cable gland, etc.

Flexible Pipe type:

PP/PA flexible pipe, metal flexible pipe, bellows fixed frame, etc.

Vent valve series:

Breathable vent plug and breathable cable gland, etc.

Accessories:

Brass reducer, brass enlarger, standard locknut, EMC locknut, brass screw plug and waterproof junction box, etc.





FAQ

Q: Are you trading company or manufacturer?

A: We are the factory. Also we can export the goods by ourselves.

Q: How long is your delivery time?

A: Generally we can send out the the goods within 3-7 days if the goods are in stock.

Or it is should be 7-30 days if the goods are not in stock, it is according to your order quantity.

Q: Do you provide samples? Is it free or extra?

A: Yes, we could offer the samples for free charge but do not pay the cost of freight.

Q: What is your terms of payment?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance,

balance before shipment.

Q: How about the after-sale service?

A: Any feedback or comments are welcomed

We will try to make the best assistant to let you maximum satisfaction.
